27 Help and error messages

27.3 Error messages in short form

27.3.1 General error messages

150 Planmeca Compact i
The error message tables list the error messages, which are mainly intended
to assist the technician. If an error message is displayed, contact service.
For more detailed information, see
manual .
General error messages
ERROR EXPLANATION
CODE
E1.01 Main water valve short circuit.
Disconnect valve and check if error disappears.
E1.02 Main air valve short circuit.
Disconnect valve and check if error disappears.
E1.03 Bowl rinse valve short circuit.
Disconnect valve and check if error disappears.
E1.04 Cup filling valve short circuit.
Disconnect valve and check if error disappears.
E1.05 Water flush valve short circuit.
Disconnect valve and check if error disappears.
E1.06 Separator pulse valve short circuit.
Disconnect valve and check if error disappears.
E1.07 Ejector valve short circuit.
Disconnect valve and check if error disappears.
E1.08 Extra out 1 short circuit.
Disconnect output and check if error disappears.
E1.09 Extra out 2 short circuit.
Disconnect output and check if error disappears.
E1.10 Extra out 3 short circuit.
Disconnect output and check if error disappears.
E1.11 Separator start signal / Microvac's start valve short circuit.
E1.12 Assistant syringe water valve short circuit.
Disconnect valve and check if error disappears.
E1.13 Separator alarm reset signal short circuit.
Disconnect output and check if error disappears.
E1.14 PLANET output (ELMP) short circuit.
Disconnect output and check if error disappears.
E2.01 Incoming water valve open circuit.
Error can be detected when circuit is dead.
E2.02 Incoming air valve open circuit.
Error can be detected when circuit is dead.
