EMC VNX Series Hardware Information Manual page 27

• RS-232/EIA status LEDs
• SP latch handles (bottom, left and right)
Figure 16 shows the location of these components.
1
13
12
1 AC (power in) recessed connector (plug)
2 Power supply fault LED (amber)
3 Power supply power on LED (green)
4 Power supply latch handle
5 Two I/O module slots showing a four-port
8-Gb/s Fibre Channel (FC) I/O module and
a four-port 1-Gb/s iSCSI I/O module
6 Two SP latch handles (bottom left and
right)
7 Two 6-Gb/s SAS ports
Figure 16 Example of SP components (rear view)
4
3
2
8Gb
fibre
5
2 3 4
11
9 8
10
8 Two RJ-45 (management and service
laptop) connectors (labeled with a
network management symbol and a
wrench symbol, respectively)
9 SP unsafe to remove LED
10 SP fault LED (amber)
11 SP power on LED (green)
12 Two RS-232/EIA (micro DB-9) connectors
(labeled with a battery symbol and a
wrench symbol, respectively)
13 Four 8-Gb/s Fibre Channel ports (labeled
8Gb fibre 2, 3, 4, and 5)
VNX5500 Hardware Information Guide
System component description
5
PART NUMBER PART NUMBER
REV A09 A REV A09 A
6Gb
SAS
1 X4
6Gb SAS
0 X4
7 6
VNX-000568
27
