4-6
Compact™ IO Isolated Thermocouple Module
Hex
Error Type
Equivalent
X405
X406
X407
X408
X409
X40A
X40B
X40C
X40D
X40E
X40F
X410
X411
X412
X413
X414
X415
X416
X417
X418
X419
Section 4.8
Module Inhibit

Function

User's Manual Pub. 0300244-02 Rev. A

Module

Extended Error
Error
Information Code
Code
(Binary)
(Binary)
010
0 0000 0101
010
0 0000 0110
010
0 0000 0111
010
0 0000 1000
010
0 0000 1001
010
0 0000 1010
010
0 0000 1011
010
0 0000 1100
010
0 0000 1101
010
0 0000 1110
010
0 0000 1111
010
0 0001 0000
010
0 0001 0001
010
0 0001 0010
010
0 0001 0011
010
0 0001 0100
010
0 0001 0101
010
0 0001 0110
010
0 0001 0111
010
0 0001 1000
010
0 0001 1001
Some controllers support the module inhibit function. See your controller manual
for details.
Whenever the 1769sc-IT6I module is inhibited, the module continues to provide
information about changes at its inputs to the 1769 CompactBus master (for
example, a CompactLogix controller).
Error Description
invalid input type selected ch4
invalid input type selected ch5
invalid input filter selected ch0
invalid input filter selected ch1
invalid input filter selected ch2
invalid input filter selected ch3
invalid input filter selected ch4
invalid input filter selected ch5
Invalid input format selected ch0
Invalid input format selected ch1
Invalid input format selected ch2
Invalid input format selected ch3
Invalid input format selected ch4
Invalid input format selected ch5
An unused bit has been set for ch0
(C:e.0)
An unused bit has been set for ch1
(C:e.1)
An unused bit has been set for ch2
(C:e.2)
An unused bit has been set for ch3
(C:e.3)
An unused bit has been set for ch4
(C:e.4)
An unused bit has been set for ch5
(C:e.5)
An unused bit has been set for Module
Configuration Register (C:e.6)
