Chapter 2: Installation and Wiring
WARNING
WARNING
WARNING
User's Manual Pub. 0300244-02 Rev. A
When attaching I/O modules, it is very important that the bus connectors
are securely locked together to ensure proper electrical connection.
7. Attach an end cap terminator (5) to the last module in the system by
using the tongue-and-groove slots as before.
8. Lock the end cap bus terminator (6).
A 1769-ECR or 1769-ECL right or left end cap respectively must be used
to terminate the end of the 1769 communication bus.
2.6.3 Panel Mounting
During panel or DIN mounting of all devices keep them free of debris and
avoiding overheating:
•
Do not remove protective debris strip until after the module and
all other equipment near the module is mounted and the wiring is
complete.
•
Once wiring is complete, and the module is free of debris,
carefully remove protective strip.
•
Failure to remove strip before operating can cause overheating.
Mount the module to a panel using two screws per module. Use M4 or #8
panhead screws. Mounting screws are required on every module.
