Spectrum Controls 1769 Series User Manual page 52

A-2 Compact™ IO Isolated Thermocouple Module
Input Description
Thermocouple Type
N (-210 °C to -200 °C)
Thermocouple Type
T (-230 °C to 400 °C)
Thermocouple Type
T (-270 °C to -230 °C)
Thermocouple Type
K (-225 °C to 1370 °C)
Thermocouple Type
K (-270 °C to -225 °C)
Thermocouple Type
E (-210 °C to 1000 °C)
Thermocouple Type
E (-270 °C to -210 °C)
Thermocouple Types
S and R
Thermocouple Type C
Thermocouple Type B
User's Manual Pub. 0300244-02 Rev. A
±1.2 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±1.8 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±1 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±1.5 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±5.4 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±7.0 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±1 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±1.5 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±7.5 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±10 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±0.5 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±0.8 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±4.2 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±6.3 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±1.7 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±2.6 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±1.8 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±3.5 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
±3.0 °C maximum at 25 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
±4.5 °C maximum at 0 °C to 60 °C for 4.17 Hz, 10 Hz, 16.7 Hz, and
19.6 Hz filters.
Value
