2. Trim the signal wires to 2-inch (5 cm) lengths. Strip about 3/16 inch (5
HAZARD OF DAMAGE TO EQUIPMENT
WARNING
Be careful when stripping wires. Wire fragments that fall into a module
could cause damage at power up.
3. At one end of the cable, twist the drain wire and foil shield together,
4. At the other end of the cable, cut the drain wire and foil shield back to
5. Connect the signal wires to the terminal block. Connect the other end of
6. Repeat steps 1 through 5 for each channel on the module.
See Appendix B, Using Thermocouple Junctions for additional
NOTE
information on wiring grounded, ungrounded, and exposed thermocouple
types.
Chapter 2: Installation and Wiring
wires.
mm) of insulation away to expose the end of the wire.
bend them away from the cable, and apply shrink wrap. Then earth
ground at the preferred location based on the type of sensor you are
using. See Grounding earlier in this chapter.
the cable and apply shrink wrap.
the cable to the analog input device.
User's Manual Pub. 0300244-02 Rev. A
2-15
