Input Description
Fault detection
Approximate Shipping
Weight (with carton)
Module Dimensions
Environmental Tests
Agency Certification
Hazardous Environment
Class
Radiated and
Conducted Emissions
Electrical /EMC:
ESD Immunity
(IEC61000-4-2)
Radiated Immunity
(IEC61000-4-3)
Fast Transient Burst
(IEC61000-4-4)
Surge Immunity
(IEC61000-4-5)
Conducted Immunity
(IEC61000-4-6)
Max Current input is limited due to input impedance
Open circuit detection, over-range and under-range error bits.
Open circuit detection time is equal to the channel update time.
276 g (0.61 lbs.)
118 mm (height) × 87 mm (depth) × 35 mm (width)
Height including mounting tabs is 138 mm 4.65 in. (height) × 3.43 in
(depth) × 1.38 in (width)
Height including mounting tabs is 5.43 in.
Table A-2 EMC Specification Table
Description
C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Class I, Division 2, Hazardous Location, Groups A, B, C, D
(ISA 12.12.01, C-UL under CSA C22.2 No. 213)
Operating Temperature Code T5
IEC61000-6-4 FCC Part 15B Class A
The module has passed testing at the following levels:
4 kV contact, 8 kV air
10 V/M, 80 to 1000 MHz, 80% amplitude modulation, 900 MHz &
1890 MHz 100% amplitude modulation
4 kV
2 kV Line - Line, 4 kV Line - GND
10 V, 0.15 to 80 MHz
Appendix A: Specifications
Value
User's Manual Pub. 0300244-02 Rev. A
A-5
