Access through the Console Port

Access the terminal emulation program (HyperTerminal, Teraterm, ProComm) to establish a connection to the

modem command line interface. The following procedure uses HyperTerminal as the example terminal emulation

program. If you are using another terminal emulation program, refer to the user documentation for instructions.

Step

From the Start button, select Programs | Accessories | HyperTerminal.

In the HyperTerminal dialog, select File | New Connection.

Enter a name for this connection and click OK.

For Connect using, select the COM port (typically COM1) on the PC to which you have connected the

modem (console port connection), then click OK. The COM1 Properties dialog

MM70xG2-UM-03

Appendix A: Command Line Interface Access

Action

Figure A-2. COM1 Properties

(Figure

A-2) is displayed.

A-3
