C
ONFIGURING THE
The WAN configuration sets up from 1 to 32 sessions between the modem and the service provider or between two
G.shdsl modems (see Chapter 7: Implementing a Point-To-Point LAN Extension
session can be configured separately, specifying the protocol, IP address, ATM connection identifier, ATM QoS, and
more.
B Y B
EFORE OU EGIN
The following should be supplied by the service provider before configuring WAN sessions:
• Protocol for each session, where the choices are the following for a maximum of 32:
– RFC 1483-Bridge (up to 8 sessions)
– RFC 1483-Router (up to 16 sessions)
– PPPoA or PPPoE (up to 8 sessions for either type)
• IP address and subnet mask for each session using RFC 1483-Router protocol.
• RIP version (each direction) for each session using RFC 1483-Router protocol or PPP:
– RIP Version1
– RIP Version 2
– RIP Version 1 and RIP Version 2
• Encapsulation for 1483-Bridge or 1483-Router, where the choices are:
– LLC
– VCMux
• Login and authentication for each session using PPP protocol, where the choices are:
– login name and password
– authentication type of either PAP, CHAP or None
• ATM parameters for each session, including:
– VPI and VCI values
– Quality of Service (QoS) which could be UBR or CBR and applicable cell rates
Note: The modem is shipped with factory defaults as a Remote modem.
With V3.2.0, there are two RFC-1483 WAN Bridging sessions with PVC's 0/35 and 0/100. For point-to-point
LAN extension applications, delete one WAN session.
MM70xG2-UM-03
WAN
Chapter
for more information). Each
4
4-1
