Chapter 9: Managing the Modem
The following is a description of the fields at the top of the Status page:
• Device Name
Identifies the modem and its LAN connection type (Ethernet port). This is not a configurable parameter.
• Firmware Release
Identifies the version number of the software image currently used on the modem.
• Model
Identifies the model of the modem.
• MAC Address
Identifies the unique, hardware address assigned to and resident on the modem.
• DSP Version
Identifies the version of the G.shdsl firmware driver used for the modem.
The following is a description of the fields in the Summary of current settings table:
• DSL Status
Provides configuration values specific to G.shdsl, including:
– Modulation—Indicates the G.shdsl transmission standard to which the modem is set.
– State—Status of the DSL link.
– Data Rate TX—Bit rate at which the is configured to send data.
– Data Rate RX—Bit rate at which the is configured to receive data.
– SNR Margin (DB)—Current SNR margin in decibels.
• WAN Session
See
"Configure a New WAN Session" on page 4-2
• LAN
See
"Configure the LAN" on page 3-1

View System Log

The Configuration Error Log shows errors that have occurred during the time the modem is operational. This error
log is used by the manufacturer for internal use only.
Select System on the menu bar, then select System Log under System to access the Configuration Error Log
page
(Figure
9-2).
9-2
for definitions of WAN Session fields.
for definitions of LAN fields.
April 14, 2006
MM70xG2-UM-03
