Step
2 View the current statistics as described below:
• Operational State
Indicates the current mode of the modem. Operational states include:
– Handshaking—indicates that the modem is negotiating with the DSLAM or the other modem.
– Training—indicates that the modem is learning the connection parameters.
– Show time—indicates the G.shdsl connection is operational.
• Data Rate
Indicates the bit rate for this transmission on the G.shdsl connection.
• DSP Version
Indicates the version of G.shdsl firmware driver used on this modem.
• Transmission Power
Indicates the local transmission power in decibels.
• Receiver Gain
Indicates the amplifying factor for incoming signal in decibels.
• Local SNR Margin
Indicates the actual value for the SNR margin.
• Loop Attenuation
Indicates the current and approximate loop attenuation (loop signal loss) in decibels.
• Framer Sync
Indicates the current status of G.shdsl frame synchronization.
