Appendix A: Command Line Interface Access

C C
ONNECT TO THE
Step
1 Install the flat gray console cable between the modem Console port and your PC (see
the DB-9 port adapter on the PC, if required.

Access the Command Line Interface

You can access the command line interface through the direct connection to the modem console port using a
terminal emulation program. You can also access the command line interface using a telnet session. To use a telnet
session, you must have IP access to the modem either through the 10/100Base-T LAN port (LAN-side access) or
through an IP address assigned to a WAN session (WAN-side access). The following sections provide instructions
for setting up both types of command line interface access.
A-2
P
ONSOLE ORT
Figure A-1. Connect to the Console Port
Action
April 14, 2006
Figure A-1), using
MM70xG2-UM-03
