Chapter 7: Implementing a Point-to-Point LAN Extension
Step
5 Select Save Changes on the menu bar to access the Save Changes page
6 Click Save to save the configuration to flash memory.

Configure the Central-Office Modem

To configure the central-office modem, you need to change the following settings:
• Operating mode for the modem, (see
• WAN parameters, (see
• LAN parameters, (see
Configure the Central-Office Operating Mode
Step
1 Select DSL on the menu bar; then select Advance Configuration under DSL Options.
Figure 7-8. G.SHDSL Advanced Configuration—Change CO Operating Mode
2 In the Operating Mode box, select CO to configure the modem for this mode.
3 Click Apply.
7-6
Figure 7-7. Save Changes Page
"Configure the Central-Office Operating Mode" on page
"Configure the Central-Office WAN" on page
"Configure the Central-Office LAN" on page
Action
7-7)
7-8)
Action
April 14, 2006
(Figure 7-7).
7-6)
MM70xG2-UM-03
