Permanently Save Sessions; Edit An Existing Session - ADC MM701G2 User Manual

April 14, 2006
Step
1 • PPP Authentication
(cont.)
Enter 13 then select the authentication protocol provided by your service provider for PPP sessions.
The authentication protocol type must match at the modem and the service provider. The options
are:
1—NO Authentication is required for the session.
2—PAP where the modem sends authentication requests to the service provider and authentication
occurs only once during the life of the link.
3—CHAP where the service provider returns an authentication challenge to the modem during the
authentication.
• User Name
Enter 14 then type the login name for this PPP session to the Login name supplied by the service
provider. Minimum login name length is one character and the maximum is 32 characters.
• User Password
Enter 15 then type the login password for this PPP session to the Login password supplied by the
service provider. Minimum password length is six characters and the maximum is 32 characters.
2 Enter 16 to Apply the new setting and to add the new RFC1483 bridged session to your session list; or
you can enter 17 to Delete session.

Permanently Save Sessions

After you have set up all the WAN sessions, select Save Current configuration from the System Management
main menu as described in
or power cycle the modem.

Edit an Existing Session

Step
1 On the WAN Session Management menu
The WAN Session View/Edit screen is displayed
MM70xG2-UM-03
"Saving the Current Configuration" on page A-28
(Figure A-7 on page
Figure A-11. WAN Session View/Edit
Appendix A: Command Line Interface Access
Action
or the changes will be lost if you reboot
Action
A-8), enter 1 to View/Edit existing session.
(Figure A-11).
A-15
