The following table shows which six-bit data byte is transmitted for each button on the remote. The
button definitions in italics are discrete codes not physically accessible on the Programmer's Remote,
but are available to send to SceneStation for advanced functionality.
Button
EDIT
OPTION
POWER
RECORD
COPY
LOCK
CHANNEL
UP ARROW
PERCENT
LEFT ARROW
ENTER
RIGHT ARROW
CANCEL
DOWN ARROW
BUMP
1
2
3
4
5
6
80 | Appendix B: IR Code Specifications
RC5 Data Byte
$00
$01
$02
$03
$04
$05
$06
$07
$08
$09
$0A
$0B
$0C
$0D
$0E
$0F
$10
$11
$12
$13
$14
Button
7
8
9
CLEAR
0
DECIMAL
FADE
FOLLOW
LOOP
SCENE
INDICATOR
REPEAT
MASTER UP
MASTER DOWN
POWER ON
POWER OFF
BUTTON 1
BUTTON 2
BUTTON 3
BUTTON 4
BUTTON 5
SceneStation Installation and Programming Guide
RC5 Data Byte
$15
$16
$17
$18
$19
$1A
$1B
$1C
$1D
$1E
$1F
$20
$2C
$2D
$2E
$2F
$30
$31
$32
$33
$34
