Example 7: Program a Button to Activate Multiple Presets

This example demonstrates how to create a button that activates the next preset from a list each
time it is pressed.
This example assumes you have several presets such as 10, 11, 12, 13 that you want the button to
activate, one at a time with each button press.
The following procedure will first create a loop with these presets by setting Preset 13 to loop back to
Preset 10. Then, a button will be assigned to this group with a button mode of "sequential":
Action
Select the last Preset in the group. In this
example, we'll edit Preset 13.
Set the Loop to Preset 10.
Store the changes to Preset 10.
Select the Button to be programmed. In
this example, we'll use Button 2.
Enter the preset number of the Preset you
want this button to activate (Preset 10 in
this example).
Change the Button Function to
"Sequential".
Store the changes.
When this procedure is complete, the first time you press Button 2, the station will activate Preset
10. A second press of Button 2 will activate Preset 11. Then, Preset 12 and 13. A fifth press of the
button will activate Preset 10 again, because of the loop back to Preset 10 from Preset 13.
74 | Programming Examples
Using SceneStation Studio
Open the station editor window and click
the Presets tab. Then, click on Preset 5
in the list.
Choose Preset 10 in the pop-up menu.
N/A
Switch to the Buttons tab. Then, click on
Button 2 in the list.
Choose "Preset 10" from the Preset
pop-up menu.
Choose "Sequential" from the Function
pop-up menu.
Click on the Sync button to send the
changes to the station, or use the File >
Save menu to save the changes to a file.
Using the Programmer's Remote
Press EDIT, and enter two-digit Preset
number, "13". Then, press LOOP.
Press LOOP, then enter the preset to
loop to. In this example, enter "10".
Press ENTER to save the changes.
Press EDIT, and then press the physical
button you want to program. The button
will quickly flash White.
Enter the two-digit preset number, "10".
Press EDIT followed by the physical
button again. Next, press OPTION + 3 to
set the Function to "Sequential".
N/A
