Installation

SceneStation is designed to be installed into either a standard single-gang electrical box for
Architectural applications or in our portable enclosure for temporary applications.

Architectural

For architectural installations, SceneStation is typically installed "in-wall" by use of a standard single-
gang electrical box. SceneStation is approximately the same size as a standard residential dimmer
switch (see specifications for exact dimensions).
SceneStation comes with a two-piece designer wall plate that finishes the installation with a profes-
sional look that shows no visible hardware (screws). Multiple gang wall plates are also available. If
desired, SceneStation can also be mounted in a 3rd party Decora® style wall plate, however you
may need additional mounting screws if using your own wall plate.
Power for the station is supplied by a Class 2 transformer that provides between 11 to 28 volts DC
(5W minimum), or 14 to 28 volts AC (5VA minimum).
If the station is going to be used to output DMX to one or more lighting fixtures, a suitable DMX cable
should be run from the station location to the first DMX fixture. Additional DMX fixtures are daisy-
chained from the first fixture.
If the station requires a DMX input from another source, a separate DMX cable must be run from the
other controller to the station.
If the station is going to be used only as a wireless slave to another station, no DMX cabling is
required.
See the figure on the next page for a diagram of the typical wiring connections to SceneStation.
