Number Buttons Function
This option selects the behavior of the numeric buttons (0 thru 9) on the User's Remote. The
choices are:
•
Ten Programmable Function Buttons
The numeric buttons will behave as ten programmable function buttons that are similar to
the front-panel buttons on the station. Use the Buttons Tab in the editor window to set
each function and preset as desired for each button on the remote.
•
Numeric Entry for Two-Digit Preset Numbers
The numeric buttons will behave as a numeric entry to specify any of the 64 presets in
SceneStation. When the remote is in this mode, press "1" then "3" to activate preset 13.
For presets 0 thru 9, press Zero first (for example, "0" then "7" to activate preset 7).
Up/Down Arrows Function
This option selects the behavior of the Up and Down arrow buttons on the User's Remote. The
choices are:
•
Grandmaster Up/Down
The arrows will raise and lower the Grandmaster, which is the overall brightness output of
the SceneStation.
•
Next/Previous Preset
The arrows will step to the next or previous preset, in numerical order (or in sequence
order if the current preset is part of a loop).
•
None
This arrows will have no function.
Enable Programmer's Remote
The Enable Programmer's Remote setting is used to choose which Programmer's Remote should
be paired with this station, or if it should be disabled completely.
The Programmer's Remote has the ability to be set to one of six different codes. Choose the
desired code number with this popup menu.
Choose Default to use the IR Remote Code as chosen by the DIP Switches on the back of the
station.
SceneStation Installation and Programming Guide
Using SceneStation Studio | 27
