Example 3: Set Timing Parameters for a Preset

This example demonstrates how to change the timing parameters for a preset.
The following procedure will modify Preset 1 to have a 3.5 second fade time and a 1 minute follow
time. This means that when activated, Preset 1 will fade up in 3.5 seconds and 1 minute after being
activated the next preset (Preset 2) will automatically activate.
Action
Select the Preset to be edited. In this
example, we'll edit Preset 1.
Adjust the Fade Time to 3.5 seconds.
Adjust the Follow Time to 1 minute.
Store the changes.
After this procedure is complete, press Button 1 on the station (or type "01" on the remote) to acti-
vate Preset 1. Preset 1's channels will fade up over 3.5 seconds. Also, 10 seconds after activating
Preset 1, the next preset (Preset 2) will automatically be activated.
70 | Programming Examples
Using SceneStation Studio
Open the station editor window and click
the Presets tab. Then, click on Preset 1
in the list.
Enter the time into the Fade Time
field. You can type a number, or use
the Up/Down arrows. Select the time
units (Seconds, Minutes or Hours). In
this example, enter 3.5 and choose
"Seconds" in the pop-up menu.
Enter the time into the Follow Time field.
You can type a number, or use the Up/
Down arrows. Select the time units
(Seconds, Minutes or Hours). In this
example, enter 1 and choose "Minute" in
the pop-up menu.
Click on the Sync button to send the
changes to the station, or use the File >
Save menu to save the changes to a file.
Using the Programmer's Remote
Press EDIT, and then the two-digit Preset
number, "01".
Press FADE, then enter the desired Fade
Time in seconds. In this example, enter
"3.5".
Press FOLLOW, then enter the desired
Follow Time in seconds. In this example,
enter "60".
Press ENTER to save the Preset after
adjusting the Preset's levels.
