DMX Record Mode

This mode is used to capture the DMX channel levels of an external source, such as a lighting
console or controller and store these levels into one of the 64 presets in SceneStation.

Record a DMX Snapshot

When an external DMX source is controlling the lighting fixtures, the current scene
can be captured into one of the 64 preset memories in SceneStation.
To enter the DMX Record mode, press RECORD. The even-numbered LEDs on the
station will begin blinking Green.
If no DMX input is detected, all LEDs will briefly flash Red.
Then, enter the two-digit preset number to record the current DMX channel values into.
For example, to record the incoming DMX values into Preset 3, press:
RECORD + 03
When the scene is successfully recorded, all LEDs on the station will briefly flash Green.
The station is now ready to record another snapshot. You can adjust the levels of the lighting
fixtures and enter the two-digit preset number to record another snapshot.
When finished recording scenes, press CANCEL.
When recording scenes in this manner, the other properties of the preset (such as Fade,
Note:
Follow, Loop, Repeat, etc.) are not modified from their previous values. To change
these properties, use the Preset Edit Mode as described earlier.
