Appendix A: Pairing The Programmer's Remote

The SceneStation Programmer's Remote can be programmed to output one of six unique remote
codes, which enables the pairing of specific remotes with specific stations.

Setting the IR Code on the Remote

To set the IR Code on the Programmer's Remote, follow these simple steps:
Step 1: Press and hold both the POWER and ENTER buttons for 3 seconds. The LED on
•
the remote will turn on after 3 seconds. Release the buttons.
Step 2: Press "1" within 3 seconds.
•
Step 3: Press one of the property buttons as shown in the following table within 3 seconds:
•
Step 4: Press ENTER. The LED on the remote will blink twice to confirm that it has accepted
•
the change.

Setting the IR Code on the Station

To set the IR code on the SceneStation, you can either use the SceneStation Studio software or you
can set the dip switches on the back of the station.
With the SceneStation Studio software (only available if the station has the wireless option), open
the station editor window and click on the IR Receiver tab. Then, choose the desired IR code(s) to
respond to by choosing a selection from the Pair With Remote popup menu.
To change the IR code using the dip switches on the back of the station, see the chapter above on
Hardware Configuration.
SceneStation Installation and Programming Guide
Desired Code
1
2
3
4
5
6
Property Button
SCENE
INDICATOR
REPEAT
FADE
FOLLOW
LOOP
