Button Edit Mode

The Button Edit Mode is used to edit the properties of a button. The properties of a button include
its function and the preset it activates.
The following sections describe how to edit the various properties of a button.

Set a Button's Preset

Each button activates a preset. To change the preset that a button activates, begin
by pressing EDIT, and then press the physical button you want to change.
The button on the station you are editing will quickly flash White.
Then, press the two-digit number of the preset you want the button to activate (from
00 to 64).
The button will now activate the specified preset and the station returns to the Idle Mode.

Set a Button's Function

Each button uses its Button Function to determine how it will activate a preset. To
change the function of a button, begin by pressing EDIT, and then press the physi-
cal button you want to change.
The button on the station you are editing will quickly flash White.
Next, press OPTION to switch to the Button Function mode. The button will begin
to quickly flash Yellow.
Finally, press one of the digits below to change the button's function:
1 = Normal - The button will activate its preset.
•
2 = Toggle - The button will toggle the specified preset on and off. If the button is not
•
active, a press will activate the preset. If the button is active, a press will deactivate the
preset.
3 = Sequential - The button will activate the specified preset when pressed. Then, while
•
the button is active, each additional press will step manually from the current preset to
the next preset. This function follows the normal sequence of presets on each press,
including loops and repeat counts. This function is useful for making a single button
able to select one of several different presets.
4 = Latched - The button will activate the specified preset only if the button is not cur-
•
rently active. This function is useful for making sure that a second press of a button
doesn't restart a chase or loop of presets.
