3. On the Home page, review the setup details and navigation buttons described in
Note
Web Page Item
Admin Settings
Username
Password
Confirm Password
Current Status
Serial Number
Mac Address
Firmware Version
Partition 2
Partition 3
Booting From
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
SIP Volume
Multicast Volume
Ring Volume
Sensor Volume
Push to Talk Volume
Microphone Gain
Push to Talk Microphone Gain
SIP Mode
Multicast Mode
Event Reporting
Nightringer
Primary SIP Server
Backup Server 1
Backup Server 2
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-6. Home Page Overview
Description
The username to access the web interface. Enter up to 25 characters.
The password to access the web interface. Enter up to 25 characters.
Confirm the web interface password.
Shows the device serial number.
Shows the device Mac address.
Shows the current firmware version.
Contains a complete copy of bootable software.
Contains an alternate, complete copy of bootable software.
Indicates the partition currently used for boot.
Allows the user to boot from the alternate partition.
Shows the current IP addressing setting (DHCP or static).
Shows the current IP address.
Shows the current subnet mask address.
Shows the current default gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Shows the current SIP volume level.
Shows the current Multicast volume level.
Shows the current Ring volume level.
Shows the current Sensor volume level.
Shows the current push to talk volume
Shows the current microphone gain level.
Shows the current push to talk microphone gain level.
Shows the current status of the SIP mode.
Shows the current status of the Multicast mode.
Shows the current status of the Event Reporting mode.
Shows the current status of the Nightringer mode.
Shows the current status of the Primary SIP Server.
Shows the current status of Backup Server 1.
Shows the current status of Backup Server 2.
931667A
Installing the SIP Outdoor Video Intercom with RFID
) in the following table shows which web page items will be defined
.
Intercom Setup
Table 2-6.
