Confirm Operation - CyberData InformaCast Enabled 011406 Operation Manual

2.2.19 Confirm Operation

After connecting the device to the 802.3af compliant ethernet hub, use the LEDs on the device to
confirm that the device is operational and linked to the network.
LED
Power (PWR)
Status
Speed (SPD)
Link/Activity (Link/Act.)
Figure 2-25. InformaCast Enabled Loudspeaker Amplifier (AC-Powered) LEDs
Operations Guide
Table 2-7. InformaCast Enabled Loudspeaker Amplifier (AC-Powered) LEDs
Color
BLUE/ GREEN
GREEN
AMBER
GREEN
Speed (SPD) LED
(AMBER)
Power (PWR) LED
(BLUE/GREEN)
Function
The 802.3at power injector that is provided with the device should
cause the Power (PWR) LED to illuminate
power is available.
The Power (PWR) LED may illuminate
(802.3af) power source is used (not included and sold separately).
After supplying power to the device, a steady
illuminates.
After about 20 seconds, the
indicate that the device is acquiring an IP address and attempting to
GREEN
autoprovision. The
the device has finished booting. When the device has fully booted,
the GREEN Status LED will turn on solid to confirm the device is
operational.
GREEN
The Status LED will blink during a page when it is online.
The Speed (SPD) LED illuminates
for 10MB when the network link to the device is established.
The Link/Activity (Link/Act.)
network traffic.
Volume
SPD
Link/Activity (Link/Act.) LED
(GREEN)
Status LED
PWR Status
(GREEN)
