CyberData InformaCast Enabled 011406 Operation Manual page 56

Web Page Item
Force 802.3AT Mode (NOT recommended)
Auxiliary Power Supply
Line-In Settings
Enable Line-in to Line-out Loopback
DTMF Settings
Require Security Code
Security Code
Enable Stored Message Playback
Relay Settings
Activate Relay with DTMF Code
Relay Pulse Code
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Activate Relay During Ring
Activate Relay During Night Ring
Activate Relay While Call Active
Misc Settings
Device Name
Auto-Answer Incoming Calls
Operations Guide
Table 2-11. Device Page Parameters (continued)
Description
Enable this option if you are sure this speaker is connected to an 802.3AT
power source, but it is not being detected correctly (not recommended).
This device can be connected to a +24VDC auxiliary power supply.
Check this box if this is how this speaker is being powered.
Line-in audio will play back out the device's audio output ports. This is the
lowest priority audio and will be preempted by any other audio stream.
When selected, the user will be prompted to enter a Security Code
(entered on this page) before being able to execute a page when calling
the device.
Type the Security Code in this field. The Security Code must only use
characters '0-9', '*' and '#'. Enter up to 25 characters.
When selected, the caller will be prompted to select one of nine stored
messages to play through the speaker. Stored messages may be
customized on the Audiofiles page.
Activates the relay when the DTMF Activation Code is entered on the
phone during a SIP call with the device. RFC2833 DTMF payload types
are supported.
DTMF code used to pulse the relay when entered on a phone during a
SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.
Activation code used to activate the relay when entered on a phone
during a SIP call with the device. Relay will be active indefinitely, or until
the DTMF Relay Deactivation code is entered. Activate Relay with DTMF
Code must be enabled. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP
call with the device. Activate Relay with DTMF Code must be enabled.
Enter up to 25 digits (* and # are supported).
When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will not
ring and this option does nothing.
When selected, the relay will be activated as long as the Nightringer
extension is ringing.
When selected, the relay will be activated as long as the SIP call is active.
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls.
When Auto-Answer Incoming Calls
ring tone (corresponds to Ring Tone on the Audiofiles page) out of the
speaker.
931281I
is disabled, the device will play a
