2.2.21.6 External Volume Dial
To adjust the InformaCast Enabled Loudspeaker Amplifier (AC-Powered) volume with the external
volume dial, complete the following steps:
1. Turn the external Volume dial
Note
Operations Guide
(AC-Powered) face.
For the lineout volume, the volume is fixed and the volume control is adjusted through an
external amplifier.
(Figure
2-27) on the InformaCast Enabled Loudspeaker Amplifier
Figure 2-28. External Volume Dial
Volume
SPD
PWR Status
931281I
External volume dial
CyberData Corporation
