CyberData InformaCast Enabled 011406 Operation Manual page 87

2. On the Sensor page, enter values for the parameters indicated in
Note
Web Page Item
Sensor Settings
Sensor Normally Closed
Sensor Timeout (in seconds)
Activate Relay
Play Audio Locally
Make call to extension
Dial Out Extension
Dial Out ID
Play recorded audio
Repeat Sensor Message
Sensor Strobe Settings
Blink Strobe on Sensor
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-21. Sensor Page Parameters
) in the following table shows which web page items will be defined
.
Description
Select the inactive state of the sensor. The sensor is also known
as the Sense Input on the device's terminal block.
The time (in seconds) the device will wait before it performs an
action when the on-board door sensor is activated. The action(s)
performed are based on the configured Sensor Settings below.
Enter up to 5 digits.
When selected, the device's on-board relay will be activated until
the on-board sensor is deactivated.
When selected, the device will loop an audio file out of the
speaker until the sensor is deactivated.
When selected, the device will call an extension when the on-
board door sensor is activated. Use the
below to specify the extension the device will call.
Specify the extension the device will call when the on-board
sensor is activated. Enter up to 64 alphanumeric characters.
An additional Caller identification string added to outbound calls.
Enter up to 64 alphanumeric characters.
When selected, the device will call the
play an audio file to the phone answering the SIP call
(corresponds to Sensor Triggered
page).
The number of times to repeat the audio message through the
local speaker or to the remote endpoint. A value of 0 will repeat
the message while the sensor is active. Enter a value from 0-
65536.
When selected, the Strobe will blink a scene when the sensor is
triggered.
Select desired scene (only one may be chosen).
Strobe will blink ON at the specified brightness for 150ms then
OFF for 350ms during the duration of the event.
Strobe will increase in brightness from 0 to the specified
brightness and back to 0 over the course of about 3.5 seconds
during the duration of the event.
Strobe will increase in brightness from 0 to the specified
brightness and back to 0 over the course of about 1.5 seconds
during the duration of the event.
Strobe will blink ON at the specified brightness for one second
then OFF for one second during the duration of the event.
931281I
Table 2-21.
Dial Out Extension field
Dial Out Extension and
on the Audiofiles Page
