2.2.5 Confirm Operation

After connecting the Paging Amplifier to the ethernet hub, use the LEDs on the Paging Amplifier
face to confirm that the Paging Amplifier is operational and linked to the network.
LED
Power
Status
Link
Activity
Operations Guide
Table 2-7. Paging Amplifier LEDs
Color
Blue/Green The power LED is illuminated a steady
low power mode. The power LED is illuminated a steady
amplifier is in high power mode. The power LED will blink during a boot up or
a phone call.
Green After supplying power to the Paging Amplifier, a steady LED confirms that
the Paging Amplifier is operational. The status LED will blink during a page
when it is online.
Green/Yellow The Link LED is illuminated
100Mb link when the network link to the Paging Amplifier is established.
Green The Activity LED blinks to indicate network traffic.
Figure 2-11. Paging Amplifier LEDs—Power and Link
Figure 2-12. Paging Amplifier LEDs—Status and Activity
930363B
Installing the VoIP V2 Paging Amplifier
Function
green when the power is on and in
green for a 10Mb link or yellow/green
Power LED (blue/green)
Link LED (green/yellow)
Status LED (green)
Activity LED
(green)(yellow)
CyberData Corporation
13
Paging Amplifier Setup
blue when the
for a
