CyberData InformaCast Enabled 011406 Operation Manual page 51

3. On the Home page, review the setup details and navigation buttons described in
Note
Web Page Item
Admin Settings
Username
Password
Confirm Password
Current Status
Serial Number
Mac Address
Firmware Version
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
SIP Mode
Multicast Mode
Event Reporting
Nightringer
Primary SIP Server
Backup Server 1
Backup Server 2
Nightringer Server
InformaCast Status
Boot Time
Current Time
IC Servers
Configuration File
B'casts Accepted
B'casts Rejected
B'casts Active
Import Settings
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-10. Home Page Overview
Description
The username to access the web interface. Enter up to 25 characters.
The password to access the web interface. Enter up to 25 characters.
Confirm the web interface password.
Shows the device serial number.
Shows the device Mac address.
Shows the current firmware version.
Shows the current IP addressing setting (DHCP or static).
Shows the current IP address.
Shows the current subnet mask address.
Shows the current default gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Shows the current status of the SIP mode.
Shows the current status of the Multicast mode.
Shows the current status of the Event Reporting mode.
Shows the current status of the Nightringer mode.
Shows the current status of the Primary SIP Server.
Shows the current status of Backup Server 1.
Shows the current status of Backup Server 2.
Shows the current status of Nightringer Server.
Shows the boot time.
Shows the current time.
Shows the InformaCast server IP addresses.
Shows the configuration file.
Shows the number of B'casts accepted.
Shows the number of B'casts rejected.
Shows the number of active B'casts.
Use this button to select a configuration file to import.
) in the following table shows which web page items will be defined
.
931281I
Table 2-10.
CyberData Corporation
