2.2.9 Terminating the Network Cable Connector
Terminate the network cable connector as shown in
Figure
2-14.
Figure 2-13. Terminating the Network Cable Connector
Cable Gland
Assembly
Power Injector
Paging Amplifier Assembly
Cable Gland
Network Cable
Assembly
to Power Injector (IN)
Terminate Connector After
Cable Passed Enclosure
Operations Guide
931281I
