2.2.10 Connecting the InformaCast Enabled Loudspeaker Amplifier (AC-
Powered) to the Power Injector
Connect the InformaCast Enabled Loudspeaker Amplifier (AC-Powered) to the power injector as
shown in
Figure 2-14. Connecting the InformaCast Enabled Loudspeaker Amplifier (AC-Powered) to the Power Injector
Operations Guide
Figure
2-14.
OUT
IN
931281I
CyberData Corporation
