Web Page Item
Local SIP Port
Outbound Proxy
Outbound Proxy Port
User ID
Authenticate ID
Authenticate Password
Re-registration Interval (in seconds)
Nightringer Strobe Settings
Blink Strobe on Nightring
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
Operations Guide
Table 2-17. SIP Page Parameters (continued)
Description
The Local SIP Port is the port number the device will use to receive SIP messages for
the Nightringer extension. This value cannot be the same as the
the primary extension. The default Local SIP Port is 5061. The supported range is 0-
65536. Enter up to 5 digits.
Enter the Outbound Proxy address as an IPv4 address in dotted decimal notation or a
fully qualified domain name (FQDN). When an IP address is configured, the device
will send all SIP messages to this IP address for the Nightringer extension. When an
FQDN is configured, the device will run DNS NAPTR, SRV, and A queries on the
FQDN to resolve an IP address to which it will send all SIP messages for the
Nightringer extension. This field can accept entries of up to 255 characters in length.
The Outbound Proxy Port is port number used as the destination port when sending
SIP messages to the outbound proxy for the Nightringer extension. A value of 0 will
default to 5060. The supported range is 0-65536. Enter up to 5 digits.
Specify the SIP User ID for the SIP server. This parameter becomes the user portion
of the SIP-URI for the device's Nightringer extension. Enter up to 64 alphanumeric
characters.
Specify the Authenticate ID for the SIP Server. This parameter is required for SIP
registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the SIP Server. This parameter is required for
SIP registration authentication. Enter up to 64 alphanumeric characters.
The SIP Re-registration Interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
The following strobe settings will only appear if you are using the Strobe Kit. If
you are not using the Strobe Kit, you will not see the strobe settings.
When selected, the Strobe will blink a scene when the Nightringer is ringing.
Select desired scene (only one may be chosen).
Strobe will blink ON at the specified brightness for 150ms then OFF for 350ms during
the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0 over
the course of about 3.5 seconds during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0 over
the course of about 1.5 seconds during the duration of the event.
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second during
the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink when the Nightringer is ringing. This is the maximum
brightness for "fade" type scenes.
The red LED value for Nightringer.
The green LED value for Nightringer.
The blue LED value for Nightringer.
Use this button to preview the strobe flashing behavior for the Nightringer Strobe
Settings.
931281I
Local SIP Port for
