❏ Slimdrive SL
❏ Slimdrive SL-FR 2M
Premounting instructions
Installation and service manual
GB
DE
Mat.-Nr. 105128
FR
N° de suite 108723
IT
N. mat. 108724
ES
Núm. de mat. 108725
CZ
Mat. čis 118586
Valid for software version DCU1 V1.0 / DCU1-2M V1.0
Id. No 108722
NL
Artikelnr. 108727
SE
Mat. nr. 108726
PL
Nr. id. 108728
RU
Идент. № 108729

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Slimdrive SL and is the answer not in the manual?

Questions and answers

Related Manuals for GEZE Slimdrive SL

Summary of Contents for GEZE Slimdrive SL

  • Page 1 ❏ Slimdrive SL ❏ Slimdrive SL-FR 2M Premounting instructions Installation and service manual Id. No 108722 Mat.-Nr. 105128 Artikelnr. 108727 N° de suite 108723 Mat. nr. 108726 N. mat. 108724 Nr. id. 108728 Núm. de mat. 108725 Идент. № 108729 Mat.

  • Page 2: Table Of Contents

    Contents Safety precautions ................... 4 Overview ....................6 Diagrams ......................... 6 Tools ........................6 Torques ........................6 Components and modules ..................6 Premounting ..................... 7 Preparing profiles ..................... 7 Preparing runner ...................... 7 Installing deflection pulley ..................7 Installing geared motor .................... 8 Installing (optional) lock ...................
  • Page 3 Key to symbols ➮ Means "operation to be carried out" Means "important note" Means "additional information" Indicates parts of the text that must be read and observed. Failure to observe this information may result in injuries and damage! Danger of electric shock!

  • Page 4: Safety Precautions

    The Slimdrive SL and Slimdrive SL-FR 2M may not be used as a fire or smoke protection door. The Slimdrive SL-FR 2M is approved for use in escape and rescue paths.
  • Page 5 Before working on the electrical system: • disconnect the drive from the 230 V mains network and check to ensure that it is not supplied with power. • disconnect the controller from the 24 V battery. • note that if an uninterruptible power supply (UPS) is used, the system will still be supplied with power despite the fact that the power supply is disconnected.

  • Page 6: Overview

    Interconnection diagram DCU 1 and DCU 1 - 2M 70484-0-030 Block diagram Slimdrive SL drive 70494-0-010 Block diagram Slimdrive SL-FR 2M drive 70484-2-0572 Hood Fault elimination Faults and corrective measures DCU1, DCU1-2M controller The diagrams are subject to change. Use only the most recent versions.

  • Page 7: Premounting

    3 Premounting Preparing profiles See block diagram for lengths and processing of profiles. Preparing runner When measuring out the drive centre, keep drive extension in mind! 1. Measure centre of drive and mark on runner. Note differences between sliding blocks. 2.

  • Page 8: Installing Geared Motor

    Installing geared motor Do not hold on to the motor when transporting and installing the drive! Geared motor DCU1 (standard) Geared motor DCU1-2M (FR) 1. Place the geared motor (1) on two sliding blocks at a distance U2 (see block diagram) from the centre marking and install it with an M6 x 20 Verbus-Ripp locking bolt.

  • Page 9: Installing (Optional) Lock

    Installing (optional) lock Toothed-belt lock Use only toothed-belt lock with "24 V" label! 1. Place the locking device on two sliding blocks at the correct distance (see block diagram) from the deflection pulley and screw it down with M6 x 16 Inbus-Ripp locking bolts.

  • Page 10: Installing Toothed Belt And Toothed-Belt Locks

    Installing toothed belt and toothed-belt locks Pictured: 2-leaf 1. Calculate toothed-belt length using the formula in the block diagram. For 2-leaf doors, two toothed belts: • Left toothed belt (deflector) • Right toothed belt (motor) For 1-leaf doors, one toothed belt: •...

  • Page 11: Installing Controller

    2. Place controller (3) on the runner and push tensioning plates (1) into controller (3). See block diagram for controller position. – Slimdrive SL: DCU1 controller – Slimdrive SL-FR 2M:DCU1-2M controller 3. Tighten bolts. Installing battery ➮ Position battery (1) (see block diagram) and install with M6 x 8 Inbus-Ripp locking...

  • Page 12: Installing Roller Carriage

    3.10 Installing roller carriage 1. Clean running surfaces of the runner and rollers before using the roller carriage. 2. Push the roller carriage (1) from the side into the runner in the proper position. 3.11 Installing (optional) special roller carriage The special roller carriage prevents "tipping"...

  • Page 13: Installing End Piece

    1. Push the stop buffers (1) into the existing grooves from the right and left and pre- position them. 2. Lightly tighten the stop buffers with an Allen key (2). 3.13 Installing end piece When tightening the threaded rods, the anodized layer of the end piece and the runner must be pushed through.

  • Page 14: Installing Transformer

    3.15 Installing transformer Do not yet tighten the screws; it should be possible to move the sliding blocks. 1. Screw two M6 x 8 Inbus-Ripp locking bolts into two flat sliding blocks. 2. Place transformer on runner and position it; tighten the two locking bolts. 3.

  • Page 15: Installing Hood Stay Cable And Hood Earth

    3.16 Installing hood stay cable and hood earth 1. Insert the mounting elements (1) for cords (rubber cables) at the left and right in the front groove (3) of the hood approx. 1 cm from each edge of the runner. 2.

  • Page 16: Connecting Alarm Contact At Locking Device (Optional)

    3.17 Connecting alarm contact at locking device (optional) 1. Remove M2.3 x 10 bolts on indicator switch (1) of the locking device. 2. Place alarm contact switch (2) on the indicator switch (1). 3. Secure both switches to the locking device with M2.3 x 18 (3) bolts and lock washers.

  • Page 17: Connecting Transformer And Controller

    (3) of the controller. 3.20 Connecting geared motor and controller Slimdrive SL Slimdrive SL-FR 2M Slimdrive SL 1. Lay rotary transducer cable (1) and motor connection cable (2) to controller. 2. Push the plug into the controller.

  • Page 18: Connecting Battery And Controller

    3.21 Connecting battery and controller Do not yet attach battery cable to controller! The battery is not attached to the controller until commissioning. When performing maintenance work, the battery must be disconnected from the controller! ➮ Check whether the battery cable (1) is long enough. Attach the battery extension cable (Id.

  • Page 19: Connecting Toothed-Belt Lock (Optional) And Controller

    3.22 Connecting toothed-belt lock (optional) and controller Cables must not be pinched when mounting the cover. 1. Attach cable of toothed-belt lock (Id. No. 105310) (1) to the controller (2). 2. Lay cable for toothed-belt lock, shorten if necessary, strip and attach insulated wire-end ferrules.

  • Page 20: Installing Hood Supports

    3.23 Installing hood supports ➮ Mount the hood supports (1) on the runner in the front groove with the M5 x 14 threaded rod. Number: • 2-leaf: 3 supports • 1-leaf: 2 supports 3.24 Final work 1. You may need to cut out notches in the hood for the locking device (optional) (see drawing 70484-2-0572).

  • Page 21: Operating Test

    • Accessories bag for installation profile • Display program switch • Safety label for glass door leaf *) only with 2-leaf systems 3.25 Operating test Unplug battery after operating test and leave unplugged until commissioning. The components are not tested individually. During the operating test, the following fully-installed components of the drive are tested: •...
  • Page 22 Procedure Use display program switch DCU (Id. No. 103940) only! 1 Service key 2 Display 3 Automatic key • If a fault occurs during the operating test, the test is aborted and the fault displayed. • The operating test can be conducted as often as desired. •...

  • Page 23: Installation

    4 Installation Preparations to be made by the customer Check the preparations made by the customer to ensure proper installation: • Type and loading capacity of the facade construction or sub-construction • Levelness of the installation surface • Requirements of the interconnection diagram Installation •...
  • Page 24 9. Lay light barrier cables: Pre-drill mounting profile into extension of sealing strips and lay cable in mounting profile (see block diagram). 10. Lay cable of outside control sensor: Pre-drill mounting profile in suitable position and pull in cables (see block diagram).
  • Page 25 Installing door leaves Danger of injury by broken glass! ➮ Always install the door leaves together with another person. Danger of crushing! The door leaves are still unsecured and slide easily. ➮ Ensure that the door leaves are not pushed inadvertently or by unauthorised persons.
  • Page 26 Positioning toothed-belt lock 1. Close the door leaves. 2. Loosen the screws (1) and (2) on the locking device. 3. Align the locking device to the toothed belt. After installation the locking pin must be positioned above the hole in the hood so that it can be locked and unlocked.

  • Page 27: Commissioning

    For electrical installation, see terminal connection diagram. Installing key switch The key switch is required with the Slimdrive SL-FR 2M! The key switch is optional with the Slimdrive SL. The display program switch can be engaged/disengaged with the key switch.
  • Page 28 , manually push door leaves to reduced opening width and press the ↵ key twice. With Slimdrive SL-FR 2M, the reduced opening width is only permissible if it is greater than the required width of the escape route (see Chapter 5.3).
  • Page 29 Adjusting inside motion detectors Slimdrive SL-FR 2M • Inside motion detectors have to detect movements from a speed of 0.1 m/s on (AutSchR). • To cover the prescribed detection area, two self-monitoring inside motion detectors may be necessary with large opening widths, depending on the type.

  • Page 30: Dismantling

    Installing hood Danger of injury from swivelling hood! ➮ When handling the hood, always work together with a second person. 1. Fasten hood stay cables to the mounting elements of the runner (see Chapter 3.16). 2. Attach cable for hood earth to the earth connector on the runner. 3.

  • Page 31: Service Mode

    5 Service mode Operation Access to Service mode • with display program switch DCU (Id. No. 103940) only • not in the "Night" operating mode • operation only possible while key switch is activated (with DCU1-2M) • Operation of the display program switch is not possible during the diagnosis.

  • Page 32: Functions

    Functions The functions of service mode are described in the terminal connection diagram. Learning Close door leaves before learning. ®T When using a bolt lock, set the parameter to 4 before starting the "Learn" process. The door calculates its running parameters by using the Learn function in the Service mode.

  • Page 33: Air Lock Or Vestibule Via A Program Selector (With Dcu1 Only)

    Check: 1. Switch over to the "Automatic" program. 2. Set door to the "Winter" operating mode by simultaneously pressing keys 3. Check position of reduced opening width with a tape measure by actuation or with "reduced continuous open". Cancelling Learning mode ➮...

  • Page 34: Service And Maintenance

    6 Service and maintenance Mechanical service Danger of injury from falling hood! Hood is held by an engaging mechanism and the Velcro strips of the hood mounting bracket. ➮ The hood may only be set in place and removed by two people working together. ➮...

  • Page 35: Maintenance

    Maintenance The prescribed maintenance work on the Slimdrive SL and Slimdrive SL-FR 2M are to be carried out by properly trained personnel at least once a year or when the service display on the display program switch lights up (see figure below).

  • Page 36: Fault Elimination

    7 Fault elimination Danger of injury from falling hood! Hood is held by an engaging mechanism and the Velcro strips of the hood mounting bracket. ➮ The hood may only be set in place and removed by two people working together. ➮...

  • Page 37: Electrical Faults

    Replacing roller carriage 1. Detach driver from toothed belt lock. 2. Loosen lock nut on suspension bolt of roller carriages. 3. Remove door leaf. 4. Loosen and remove terminal strip on end piece. 5. Take out end piece upward. 6. Remove buffer from runner. 7.
  • Page 38 Replacing fuse in transformer Danger of electric shock! ➮ Disconnect the system from the 230 V mains network before removing the PCB cover. 1. Insert a suitable screwdriver into the opening of the PCB cover (1) above the switch. 2. Carefully press end wall of PCB cover upward with the tip of the screwdriver. The snap catch is released.
  • Page 39 Fault messages For troubleshooting and fault descriptions, see also the list "Faults and corrective measures V1.0 - Controller DCU1 - 2M". Fault Meaning message Controller defective (24 V) Controller defective (DCU100, 12 V) No 230 V power supply Rotary transducer signal faulty DCU100 short circuit, excessive current through motor 1 Motor 1 (DCU100) defective Safety sensor close 1 (SIS1) does not switch or actuation takes...
  • Page 40 Fault Meaning message EMERLK: Actuation takes longer than 4 minutes DCU100 drive hot: Motor or controller temperature greater than 110 °C Motor thermometer: Motor thermometer defective DCU100 thermometer: Controller thermometer defective DCU100 drive overheated: Motor or controller temperature greater than 115 °C Fault on DCU100 main PCB Battery empty, not connected or defective Software of main PCB does not match software of additional PCB...

  • Page 41: Index

    8 Index Air lock Fault commissioning ....33 electrical ......37 Alarm contact mechanical ......36 connection ......16 Fault messages ......39 Final work ........20 Battery connection ......18 Geared motor installation ......11 connection ......17 Bolt lock ........9 installation ......
  • Page 42 Maintenance ......35 Tool ..........6 Mechanical ......... 34 Toothed belt Module check tension ..... 34 replacement ......37 installation ......10 Mounting profile ......23 tension ........ 34 alignment ......23 tensioning ......10 test ........35 Toothed-belt lock connection to controller ..

  • Page 43: Ec-Declaration Of Conformity

    (automatic sliding door drives, Désignation du produit) systèmes automatiques pour porte coulissante) GEZE Slimdrive SL, GEZE Slimdrive SL-FR 2M Erklärung (Declaration, Déclaration): Die genannten Antriebe sind in alleiniger Verantwortung des o.g. Herstellers entwickelt, konstruiert und gefertigt in Übereinstim- mung mit folgendenden Richtlinien und Normen.
  • Page 44 GEZE Finland 100026 Beijing, P. R. China 70022 Altamura (Bari) E-Mail: leonberg.de@geze.com Branch office of GEZE Scandinavia AB Tel. +86 (0) 10 65 81 57-32/-42/-43 Tel. +39 (0) 080 31 15 21 9 Postbox 20 Fax +86 (0) 10 65 81 57-33...
