Pcie Adapter Information By Feature Code For The Emx0 Pcie Gen3 I/O Expansion Drawer - IBM 74Y4064 Handbook

Managing pcie adapters for ibm power system l922 9008-22l; ibm power system s922 9009-22a; ibm power system h922 9223-22h; ibm power system s914 9009-41a; ibm power system s924 9009-42a; ibm power system h924 9223-42h; ibm emx0 pcie gen3 i/o expansion dra
Hide thumbs

Advertisement

Table 7. PCIe adapters supported in the 9009-41A, 9009-42A, or 9223-42H system (continued).
Feature
Description
code
EJ1D and
PCIe3 x8 cache SAS RAID internal adapter 6 Gb (FC EJ1D and EJ1M; CCIN 57D8); Adapter FRU
EJ1M
number: 01JC773
EN0A
PCIe3 16 Gb 2-port Fibre Channel Adapter (FC EN0A; CCIN 577F); Adapter FRU number: 00E3496
EN0H
PCIe3 4-port (10 Gb FCoE and 1 GbE) (FC EN0H; CCIN 2B93); Adapter FRU number: 00E3498
EN0K
PCIe3 4-port (10 Gb FCoE and 1 GbE) Copper and RJ45 Adapter (FC EN0K; CCIN 2CC1); Adapter FRU
number: 00E8140
EN0S
PCIe2 4-port (10 Gb + 1 GbE) SR+RJ45 Adapter (FC EN0S; CCIN 2CC3); Adapter FRU number: 00E2715;
Part number (Full-height tailstock): 00E2863; Part number (Low-profile tailstock): 00E2720
EN0U
PCIe2 4-port (10 Gb + 1 GbE) Copper SFP+RJ45 Adapter (FC EN0U; CCIN 2CC3); Adapter FRU
number: 00E2715; low-profile tailstock: 00E2720
EN0W
PCIe2 2-port 10 GbE BaseT RJ45 Adapter (FC EN0W; CCIN 2CC4); Adapter FRU number: 00WV507
EN12
PCIe2 FH 4-port 8 Gb Fibre Channel Adapter (FC EN12; CCIN EN0Y); Adapter FRU number 00WT107
EN13
PCIe Binary Synchronous Adapter (FC EN13; CCIN 576C)
EN15
PCIe3 4-port 10 GbE SR Adapter (FC EN15; CCIN 2CE3); Adapter FRU number: 00ND466
EN17
PCIe3 4-port 10 GbE SFP+ Copper Adapter (FC EN17, CCIN 2CE4); Adapter FRU number: 00ND463
EN1A
PCIe3 8x 2-port Fiber Channel (32 Gb/s); (FC EN1A and EN1B - RP EL5V and EL5U; CCIN 578F);
Adapter FRU number: 01FT703
EN1C
PCIe3 8x 4-port Fiber Channel (16 Gb/s); (FC EN1C and EN1D - RP EL5W and EL5X; CCIN 578E);
Adapter FRU number: 01FT698
PCIe adapter information by feature code for the EMX0 PCIe Gen3 I/O
expansion drawer
Find technical information for specific adapters that are supported for the system. Adapters can be
identified by their feature code (FC) or their custom card identification number (CCIN).
Table 8. Supported PCIe adapters in the EMX0 PCIe Gen3 I/O expansion drawer attached to a system that is
running the AIX, IBM i, or Linux operating system
Feature code
Description
2893 and 2894
PCI Express 2-Line WAN with Modem (FC 2893 and FC 2894; CCIN 576C); Adapter FRU
number: 44V5323
5729
PCIe2 FH 4-port 8 Gb Fibre Channel Adapter (FC 5729; CCIN 5729); Adapter FRU number:
74Y3467
5735
8 Gb PCI Express Dual-port Fibre Channel Adapter (FC 5735; CCIN 577D); Adapter FRU
number: 10N9824
5785
4-port Async EIA-232 PCIe Adapter (FC 5785; CCIN 57D2); Adapter FRU number: 46K6734
5899
PCIe2 4-port 1 GbE Adapter (FC 5899; CCIN 576F); Adapter FRU number: 74Y4064
EC2N
PCIe3 2-port 10 GbE NIC & RoCE SR adapter (FC EC2N; CCIN 57BE); Adapter FRU
number: 00RX875
EC2S
PCIe3 2-port 10 Gb NIC & RoCE SR/Cu adapter (FC EC2R and EC2S; CCIN 58FA);
Adapter FRU number: 01FT759
EC2U
PCIe3 2-port 25/10 Gb NIC & RoCE SFP28 Adapter (FC EC2T and EC2U; CCIN 58FB);
Adapter FRU number: 01FT756
EC38
PCIe3 2-port 10 GbE NIC & RoCE SFP+ Copper Adapter (FC EC37 and EC38 - RP EL3X
and EL53; CCIN 57BC); Adapter FRU number: 00RX859
9
Managing PCIe adapters
