+ – — power supply output (3.3 V)
ALARM — alarm terminals
TAMP — tamper terminals
IMPORTANT! Do not connect external power to the Transmitter's power outputs. This may damage the device
2. 2. Secure the Transmitter in the case. Plastic bars are included in the installation kit. It is recommendable to install
the Transmitter on them.
