AJAX Hub User Manual page 132

The detector recognizes motion and sends the first alarm immediately, but next alarms until disarming are transmitted no more than once in 5
seconds.
If a motion is detected before the system is armed, the detector will be armed not immediately, but during the next
polling by the hub.
Learn more about the algorithm of the detector operation
Anti-masking system
Masking is an attempt to block in any way the view of the detector's lens.
MotionProtect Outdoor detects the following types of masking:
•
An obstacle in front of both lenses (an object on the height of the detector and at a distance of up to 20 cm in front of
it)
• An obstacle in front of any of the lenses (an object at a distance of up to 10 cm in front of one of the lenses)
• Painting or pasting any of the lenses with an opaque substance
•
Pasting the detector front side with an opaque substance
• Applying an aerosol or painting the detector front side with lacquer/paint
