actuation of the siren, and the keypad and message in the application will notify of the successful removal of the
system from the guard mode.

Keypad Installation

Before installing the detector, make sure that you have selected the optimal location and it is in compliance with the guidelines contained in this
manual!
Keypad should be attached to the vertical surface.
1. Attach the SmartBracket panel to the surface using bundled screws, using at least two fixing points (one of them –
above the tamper). After selecting other attachment hardware, make sure that they do not damage or deform the
panel.
The double-sided adhesive tape may be only used for temporary attachment of Keypad. The tape will run dry in course of time, which may result in
the falling of the keypad and damage of the device.
2. Put Keypad on the attachment panel and tighten the mounting screw on the body underside.
As soon as the keypad is fixed in SmartBracket, it will blink with the LED X (Fault) – this will be a signal that the
tamper has been actuated.
