AJAX Hub User Manual page 191

Room
Relay mode
Contact state
Pulse duration, sec
Scenarios
Jeweller Signal Strength Test
User Manual
Unpair Device
Voltage protection — the contact will be opened when the voltage falls outside the limits of 6.5–36.5 V.
Selecting the virtual room to which the device is assigned
Choosing the relay operation mode
•
Pulse
•
Bistable
Normal contact state
•
Normally closed
•
Normally open
Selecting the pulse duration in the pulse mode (from 0.5 to 15
seconds)
Opens the menu for creating and configuring scenarios
Switches the relay to the signal strength test mode
Opens the Relay Manual
Disconnects the relay from the hub and deletes its settings
