Holtek HT45F23A Manual page 61

HT45F23A/HT45F24A
TinyPower Flash MCU with OPA & Comparators
TM
PAWU, PAPU, PA, PAC, PBPU, PB, PBC, PCPU, PC, PCC, PD, PDC Registers
• HT45F23A
Register
Name
PAWU PAWU7
PAPU PAPU7
PA PA7
PAC PAC7
PBPU
PB
PBC
PCPU
PC
PCC
"—": Unimplemented, read as "0"
PAWUn: PA wake-up function enable
0: disable
1: enable
PAPUn/PBPUn/PCPUn: Pull-high function enable
0: disable
1: enable
PACn/PBCn/PCCn: I/O type selection
0: output
1: input
• HT45F24A
Register
Name
PAWU PAWU7
PAPU PAPU7
PA PA7
PAC PAC7
PBPU PBPU7
PB PB7
PBC PBC7
PCPU PCPU7
PC PC7
PCC PCC7
PDPU —
PD —
PDC —
"—": Unimplemented, read as "0"
PAWUn: PA wake-up function enable
0: disable
1: enable
PAPUn/PBPUn/PCPUn/PDPUn: Pull-high function enable
0: disable
1: enable
PACn/PBCn/PCCn/PDCn: I/O type selection
0: output
1: input
Rev. 1.40
7 6 5
PAWU6 PAWU5 PAWU4
PAPU6 PAPU5 PAPU4
PA6 PA5
PAC6 PAC5
— PBPU6 PBPU5 PBPU4
— PB6 PB5
— PBC6 PBC5
— PCPU6 PCPU5 PCPU4
— PC6 PC5
— PCC6 PCC5
7 6 5
PAWU6 PAWU5 PAWU4
PAPU6 PAPU5 PAPU4
PA6 PA5
PAC6 PAC5
PBPU6 PBPU5 PBPU4
PB6 PB5
PBC6 PBC5
PCPU6 PCPU5 PCPU4
PC6 PC5
PCC6 PCC5
— —
— —
— —
61
Bit
4 3 2
PAWU3 PAWU2
PAPU3 PAPU2
PA4 PA3 PA2
PAC4 PAC3 PAC2
PBPU3 PBPU2
PB4 PB3 PB2
PBC4 PBC3 PBC2
PCPU3 PCPU2
PC4 PC3 PC2
PCC4 PCC3 PCC2
Bit
4 3 2
PAWU3 PAWU2
PAPU3 PAPU2
PA4 PA3 PA2
PAC4 PAC3 PAC2
PBPU3 PBPU2
PB4 PB3 PB2
PBC4 PBC3 PBC2
PCPU3 PCPU2
PC4 PC3 PC2
PCC4 PCC3 PCC2
— — —
— — —
— — —
1 0
PAWU1 PAWU0
PAPU1 PAPU0
PA1 PA0
PAC1 PAC0
PBPU1 PBPU0
PB1 PB0
PBC1 PBC0
PCPU1 PCPU0
PC1 PC0
PCC1 PCC0
1 0
PAWU1 PAWU0
PAPU1 PAPU0
PA1 PA0
PAC1 PAC0
PBPU1 PBPU0
PB1 PB0
PBC1 PBC0
PCPU1 PCPU0
PC1 PC0
PCC1 PCC0
PDPU1 PDPU0
PD1 PD0
PDC1 PDC0
March 29, 2019
