Absolute Maximum Ratings

Supply Voltage ................................................................................................V
Input Voltage ..................................................................................................V
Storage Temperature ....................................................................................................-50˚C to 125˚C
Operating Temperature ..................................................................................................-40˚C to 85˚C
I Total ................................................................................................................................... 100mA
OL
I Total ..................................................................................................................................-100mA
OH
Total Power Dissipation ......................................................................................................... 500mW
Note: These are stress ratings only. Stresses exceeding the range specified under "Absolute Maximum
Ratings" may cause substantial damage to these devices. Functional operation of these devices at
other conditions beyond those listed in the specification is not implied and prolonged exposure to
extreme conditions may affect devices reliability.

D.C. Characteristics

Symbol Parameter
V Operating Voltage
DD
Operating Current
(HXT, ERC)
I
DD1
Operating Current
(HXT, ERC)
Operating Current
(ERC, HIRC)
I
DD2
Operating Current
(ERC, HIRC)
Operating Current
(ERC, HIRC)
I
DD3
Operating Current
(ERC, HIRC)
Operating Current
(HXT, ERC)
I
DD4
Operating Current
(HXT, ERC)
Rev. 1.40
Test Conditions
V Conditions
DD
f =910kHz,
SYS
(HXT/ERC/HIRC)
f =2MHz,
SYS
(HXT/ERC/HIRC)
—
f =4MHz,
SYS
(HXT/ERC/HIRC/EC)
f =8MHz
SYS
(HXT/ERC/HIRC/EC)
No load, f =f =455kHz,
SYS M
ADC off, LVR off,
Comparator off, OPAs off
3.3V
No load, f =f = 455kHz,
SYS M
ADC off, LVR on,
Comparator on, OPAs off
No load, f =910kHz,
M
f =f =455kHz,
SYS SLOW
ADC off, LVR off,
Comparator off, OPAs off
3.3V
No load, f =910kHz,
M
f =f =455kHz,
SYS SLOW
ADC off, LVR on,
Comparator on, OPAs off
No load, f =f =910kHz,
SYS M
ADC off, LVR off,
Comparator off, OPAs off
3.3V
No load, f =f =910kHz,
SYS M
ADC off, LVR on,
Comparator on, OPAs off
No load, f =f =1MHz,
SYS M
ADC off, LVR off,
Comparator off, OPAs off
3.3V
No load, f =f =1MHz,
SYS M
ADC off, LVR on,
Comparator on, OPAs off
13
−0.3V to V +6.0V
SS SS
−0.3V to V +0.3V
SS DD
Ta=25˚C
Min. Typ. Max. Unit
2.2 — 5.5 V
2.2 — 5.5 V
2.2 — 5.5 V
3.3 — 5.5 V
— 70 110 µA
— 100 150 µA
— 90 135 µA
— 120 180 µA
— 110 170 µA
— 160 240 µA
— 120 180 µA
— 170 260 µA
