Holtek HT45F23A Manual page 58

Register Power-on Reset
PCL ● ● 0 0 0 0 0 0 0 0
MP0 ● ● x x x x x x x x
MP1 ● ● x x x x x x x x
BP ● ● - - - - - - - 0
ACC ● ● x x x x x x x x
TBLP ● ● x x x x x x x x
TBLH ● - x x x x x x x
TBLH ● x x x x x x x x
TBHP ● - - - - - x x x
TBHP ● - - - - x x x x
STATUS ● ● - - 0 0 x x x x
SMOD ● ● 0 0 0 0 0 0 11
LVDC ● ● - - 0 0 - 0 0 0
INTEDGE ● ● - - - - 0 0 0 0
WDTC ● ● 0 1 1 1 1 0 1 0
INTC0 ● ● - 0 0 0 0 0 0 0
INTC1 ● ● - 0 0 0 - 0 0 0
MFIC0 ● ● 0 0 0 0 0 0 0 0
MFIC1 ● ● - 0 0 0 - 0 0 0
PA ● ● 1 1 1 1 1 1 1 1
PAC ● ● 1 1 1 1 1 1 1 1
PB ● - 1 1 1 1 1 1 1
PB ● 1 1 1 1 1 1 1 1
PBC ● - 1 1 1 1 1 1 1
PBC ● 1 1 1 1 1 1 1 1
PC ● - 1 1 1 1 1 1 1
PC ● 1 1 1 1 1 1 1 1
PCC ● - 1 1 1 1 1 1 1
PCC ● 1 1 1 1 1 1 1 1
PD ● - - - - - - 11
PDC ● - - - - - - 11
PAWU ● ● 0 0 0 0 0 0 0 0
PAPU ● ● 0 0 0 0 0 0 0 0
PBPU ● - 0 0 0 0 0 0 0
PBPU ● 0 0 0 0 0 0 0 0
PCPU ● - 0 0 0 0 0 0 0
PCPU ● 0 0 0 0 0 0 0 0
PDPU ● - - - - - - 0 0
PWM0 ● ● 0 0 0 0 0 0 0 0
PWM1 ● ● 0 0 0 0 0 0 0 0
MISC ● ● 0 0 0 0 - - 0 0
ADPCR ● - - 0 0 0 0 0 0
ADPCR ● 0 0 0 0 0 0 0 0
ADRL ● ● x x x x - - - -
ADRH ● ● x x x x x x x x
Rev. 1.40
TinyPower Flash MCU with OPA & Comparators
TM
RES or LVR Reset
0 0 0 0 0 0 0 0
u u u u u u u u
u u u u u u u u
- - - - - - - 0
u u u u u u u u
u u u u u u u u
- u u u u u u u
u u u u u u u u
- - - - - u u u
- - - - u u u u
- - u u u u u u
0 0 0 0 0 0 11
- - 0 0 - 0 0 0
- - - - 0 0 0 0
0 1 1 1 1 0 1 0
- 0 0 0 0 0 0 0
- 0 0 0 - 0 0 0
0 0 0 0 0 0 0 0
- 0 0 0 - 0 0 0
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
- 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
- 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
- 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
- 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
- - - - - - 11
- - - - - - 11
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
- 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
- 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
- - - - - - 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 - - 0 0
- - 0 0 0 0 0 0
0 0 0 0 0 0 0 0
x x x x - - - -
x x x x x x x x
58
HT45F23A/HT45F24A
WDT Time-out WDT Time-out
(Normal Operation) (Idle/Sleep)
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
u u u u u u u u u u u u u u u u
u u u u u u u u u u u u u u u u
- - - - - - - 0 - - - - - - - u
u u u u u u u u u u u u u u u u
u u u u u u u u u u u u u u u u
- u u u u u u u - u u u u u u u
u u u u u u u u u u u u u u u u
- - - - - u u u - - - - - u u u
- - - - u u u u - - - - u u u u
- - 1 u u u u u - - 11 u u u u
0 0 0 0 0 0 11 u u u u u u u u
- - 0 0 - 0 0 0 - - u u - u u u
- - - - 0 0 0 0 - - - - u u u u
0 1 1 1 1 0 1 0 u u u u u u u u
- 0 0 0 0 0 0 0 - u u u u u u u
- 0 0 0 - 0 0 0 - u u u - u u u
0 0 0 0 0 0 0 0 u u u u u u u u
- 0 0 0 - 0 0 0 - u u u - u u u
1 1 1 1 1 1 1 1 u u u u u u u u
1 1 1 1 1 1 1 1 u u u u u u u u
- 1 1 1 1 1 1 1 - u u u u u u u
1 1 1 1 1 1 1 1 u u u u u u u u
- 1 1 1 1 1 1 1 - u u u u u u u
1 1 1 1 1 1 1 1 u u u u u u u u
- 1 1 1 1 1 1 1 - u u u u u u u
1 1 1 1 1 1 1 1 u u u u u u u u
- 1 1 1 1 1 1 1 - u u u u u u u
1 1 1 1 1 1 1 1 u u u u u u u u
- - - - - - 11 - - - - - - u u
- - - - - - 11 - - - - - - u u
0 0 0 0 0 0 0 0 u u u u u u u u
0 0 0 0 0 0 0 0 u u u u u u u u
- 0 0 0 0 0 0 0 - u u u u u u u
0 0 0 0 0 0 0 0 u u u u u u u u
- 0 0 0 0 0 0 0 - u u u u u u u
0 0 0 0 0 0 0 0 u u u u u u u u
- - - - - - 0 0 - - - - - - u u
0 0 0 0 0 0 0 0 u u u u u u u u
0 0 0 0 0 0 0 0 u u u u u u u u
0 0 0 0 - - 0 0 u u u u - - u u
- - 0 0 0 0 0 0 - - u u u u u u
0 0 0 0 0 0 0 0 u u u u u u u u
x x x x - - - - u u u u - - - -
x x x x x x x x u u u u u u u u
March 29, 2019
