ECOFOREST Basic Installation And Maintenance Manual page 41

6. PROBLEMS AND RECOMMENDATIONS.
6.1. Do not turn the stove on and off successively because this might damage the electronical components and
motors ~230/240V - 50Hz.
6.2. Do not touch the stove while your hands are wet. Though the stove is equipped with ground plug, it remains
an electric machine that could cause electric discharge if handled incorrectly. A qualified technician only shall
resolve the eventual problems.
6.3. Do not remove any screw of the zones exposed to high temperature before they have been lubricated
properly with lubrication oil.
THE STOVE REMAINS OUT OF POWER:
6.4. Make sure the stove is connected and the plug is leading power.
6.5. Make sure the cable is not damage or cut.
While the stove is disconnected, dismantle the right side of the stove and check if any lead of the C.P.U. is
slack.
6.6. Check the C.P.U pilot. If it is OFF, check also the fuse on the C.P.U.
PELLETS DO NOT FALL AND THE STOVE DOES NOT TURN ON:
6.7. Check if there are pellets in the hopper.
6.8. Make sure the glass door is closed.
6.9. Make sure the gas outlet tube is not obstructed by anything (e.g. bird nest, plastic, etc.).
6.10. Make sure the exhaust motor works, because if it does not work fuel will not fall.
6.11. If the reducer motor does not rotate and the displays indicates the pulses, the first thing to do will be unplug
the stove and verify if the safety thermostat has been activated. With the stove unplugged, check that the
safety thermostat is located inside the stove, by opening the right side. To activate it, you must press the
button. If the thermostat is activated you will hear a "click". If the safety thermostat had been activated
before, consult your dealer.
6.12. If the reducer motor receives current and rotate slower than usually, it may have something blocked such as
a screw, a piece of wood, etc. To solve this problem, you must empty the hopper and, even if necessary, to
remove the auger screen.
WHAT NOT TO DO.
WHAT DO TO IF...
Drawing 28
40
