ECOFOREST Basic Installation And Maintenance Manual page 37

5.3. Fireplace door.
Clean the glass with a towel, using a liquid for glass cleaning, always when cold.
5.4. Ash box.
Empty the ashtray box and hoover its location.

Ash box.
5.5. Top plate of the fireplace.
In Moon and Basic models you have to push up the top plate of the fireplace (
which secure it to the center plate and pull it. When finished, put back the top plate being sure that the tabs
are properly seated.

Top plate of the fireplace.

Heat exchanger.
IMPORTANT: If the stove is operating while full of ash or residues, that might stretch the burn pot and its
support, the ash box and even the burn pot, being the cause of bad operation or possible breakdown.
WEEKLY MAINTENANCE.
MAINTENANCE AT END OF SEASON OR EVERY 500 KG OF FUEL.
Drawing 18
36
Drawing 19

), to disengage the tabs
Drawing 20
