Page 2: Flammable Material
WARNINGS GENERAL DANGER ELECTRICAL HAZARD FLAMMABLE MATERIAL HOT SURFACES OBLIGATIONS READ THE INSTRUCTION MANUAL ELECTRICAL DISCONNECTION USE OF GLOVES RISK PREVENTION WHILE HANDLING CARGO PERSON IN CHARGE AND FREQUENCY USER TECHNICIAN DAILY WEEKLY ANNUAL OR EVERY 500 KG OF FUEL... - Page 3 Read carefully this manual before using the appliance. Only that way, the best performance and maximum safety will be got during its use. This appliance can be used by children aged from 8 years and above and people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a...
- Page 4 INDEX 1. TECHNICAL FEATURES. Page 30 1.1. MIAMI DIMENSIONS (PC). Page 30 1.2. CRETA DIMENSIONS (LF). Page 30 1.3. MOON II DIMENSIONS (VS). Page 31 1.4. VIGO III DIMENSIONS (NW). Page 31 1.5. KEOPS DIMENSIONS (KP). Page 32 1.6. STOVES DATA.
- Page 5 TECHNICAL FEATURES. 1.1. MIAMI DIMENSIONS (PC). Ø100 Ø80 R8 Ø80 1.2. CRETA DIMENSIONS (LF). ...
- Page 6 1.3. MOON II DIMENSIONS (VS). 1.4. VIGO III DIMENSIONS (NW). ...
- Page 7 1.5. COTAS KEOPS (KP).
- Page 8 1.6. STOVES DATA. VIGO III KEOPS MIAMI CRETA MOON II CONNECTIONS Gas output Ø Air imput airtight pipe Ø Convection air duct Ø AIR ADMISSION Maximum air flow admission* 26,8 36,2 36,2 mBar 0,10 0,10 0,10 0,10...
- Page 9 2.3. As ECOFOREST do not have direct control on the installation of your stove, ECOFOREST do not guarantee it and do not bear the responsibility of any damage that could result from a bad use or a bad installation.
-
Page 10: Installation
(check user manual). In most cases, the combustion basket is not the same as for wooden pellets. ECOFOREST do not have any control on the quality of the fuel you use. For this reason, ECOFOREST cannot guarantee the full output of your stove nor the eventual premature aging or eventual damage of the gas outlet. The fuel’s minimum requirements are specified below:... - Page 11 If our model has a plastic protection, it must be removed before starting it. 4.10. Remove exhaust blower protection (). To connect the gas exhaust pipe to the upper outlet on the Miami model, open the door and remove the nut that secures the lid.
- Page 12 1.5 x depth of stove. See dimensions Shelf. ≥ 500 mm Depth of stove. See dimensions Drawing 5 FIXING OF MIAMI MODEL TO THE WALL. Wall-mounted stove installation. Bolts, nuts and washers. M10 minimum. Remove legs. Floor-mounted stove installation.
- Page 13 SECURITY NORMS FOR GAS OUTPUT AND AIR INPUT. 4.14. Gas output must be located in a ventilated area, not in closed or half-closed areas e.g. garage, corridor, air space of the house or places where gas may concentrate. 4.15. The external parts of the stove may reach high temperatures that might burn when touching; it is recommended to use a non flammable grid to avoid risk of burn for children and old people.
- Page 14 4 m. 4.25. The installation shown below is the one recommended by Ecoforest to get the best machine performance. The pipe section will run at least 2 meters vertically through the interior of the house.
- Page 15 4.27. When fitting stoves in brickwork chimneys a perfect seal between the flexible and the rigid pipe must be achieved. Similarly, the insulation to be placed at the contact areas between the pipe and possibly inflammable zones must be taken into account. The tube end may be left inside the chimney itself, taking into account its opening.
- Page 16 In all airtight installations, the depression must be adjusted in the offset menu to at least +10 Pa. This value may be adjusted according to the particularities of the installation and the value modification must be carried out by a qualified technician. Drawing 12 * Check modification over the offset with the stove working on level 1 and 9 during 1 hour, controllong the right combustión of the stove ( no smoke, no depressure excess, etc).
-
Page 17: Cleaning And Maintenance
POWER CABLE, ROOM SENSOR AND WiFi ANTENNA CONNECTION. An Ecoforest box is placed inside the fireplace. It contains the user manual, the installation and maintenance manual, a keyboard and keyboard support, a WiFi antenna, a power cable, a room sensor and a cleaning brush. -
Page 18: Weekly Maintenance
The deterioration of the stove parts by a lack of cleaning involves the loss of the two-year warranty offered by ECOFOREST (see warranty section). DAILY CLEANING WHEN THE STOVE IS COLD. 5.1. Burning pot & Burning pot holder. Clean the burning pot, check its holes and vacuum the burning pot holder. After cleaning, replace the burning pot correctly. - Page 19 Top plate of the fireplace. Heat exchanger. Drawing 20 IMPORTANT: If the stove is operating while full of ash or residues, that might stretch the burn pot and its support, the ash box and even the burn pot, being the cause of bad operation or possible breakdown. MAINTENANCE AT END OF SEASON OR EVERY 500 KG OF FUEL.
- Page 20 For an optimal cleaning of the extractor’s collector, it is recommended to dismantle the extractor itself in order to have full access to this zone for a better cleaning. Once the extractor is dismantled, clean it with a dry brush and be careful with the turbine and structure. Miami: Rear protection grid.
-
Page 21: Problems And Recommendations
Reducing motor of endless. Brass fitting and lubrication point. Drawing 25 5.10. Cleaning of the pellets drop tube. Use the brush provided by ECOFOREST to remove the dust until the end of the tube. Cleaning brush. Pipe of pellets fall. - Page 22 6.2. Do not touch the stove while your hands are wet. Though the stove is equipped with ground plug, it remains an electric machine that could cause electric discharge if handled incorrectly. A qualified technician only shall resolve the eventual problems. 6.3.
- Page 23 Burn pot. Burn pot support. Resistance air inlet. Resistance drive. Start-up resistance. Resistance tube support. Screw of resistance. Resistance support guide. Resistance support tube, badly fixed. Resistance support tube, badly fixed. ...
-
Page 24: Warranty
The installation must be carried out by authorized personnel, who will assume full responsibility for the final installation and the subsequent correct operation of the product. ECOFOREST will not be held responsible if these recommendations have not been followed. Installations carried out in public places are subject to specific regulations for each area. - Page 25 ECOFOREST or its dealer network. The request for intervention must be made to the company that sells the product. ECOFOREST reserves the right to include changes in its manuals, guarantees and rates without the need to notify them. Any type of suggestion and/or claim must be sent in writing to: ECOFORESTAL BIOMASS OF VILLACAÑAS, S.L.U.
- Page 26 ESQUEMA ELÉCTRICO / ELECTRICAL DRAWING / SCHEMA ELÉCTRIQUE / SCHEMA ELETTRICO / ESQUEMA ELÉCTRICO /ELEKTRISCH SCHEMA / SCHALTPLAN. Termopar Thermocouple Thermocouple Termocopia Termopar Termopar Thermoelement Conexión ethernet Ethernet connection Connexion ethernet RJ45 Connessione ethernet Conexão ethernet Ethernet-verbinding Ethernet-Verbindung Antena WiFI Aire Antenna WiFI Antenne WiFI...
- Page 28 CONTROL OF THE REVISIONS AND ANNUAL MAINTENANCE. In order to optimize the functioning of your stove ECOFOREST it is necessary to carry out the operations of maintenance detailed in chapter 5 of the instructions manual. Those that shall be done annually must be carried out by an authorized technician.
- Page 29 _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________...
- Page 30 _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________...
- Page 31 The unique valid manual is the one provided by ECOFOREST. In spite of the efforts made to make this manual as precise as possible, errors might occur during printing. In this case, please do not hesitate to communicate them to ECOFOREST.
