Physical printer port in Ethernet with TCP/IP

When using your printer in a local network with Ethernet connections and the
TCP/IP protocol, you have to assign several address informations.
Address information for the Ethernet port can only be made available by
your network administrator, who has the necessary rights to install printers
on the network and/or make any changes.
▸ The assumed address space corresponds to the TCP/IP adress, class C,
192.168.1.xxx.
▸ The subnet mask to be used is 255.255.255.0
▸ The address of the router, or gateway, is 0.0.0.0, if not available.
Example of a printer connected
to a computer in an Ethernet
Example of several devices in an
You will find more information on our
Computer 1
IP: 192.168.1.1
Computer 1
Ethernet
IP: 192.168.1.1
4-fold or 8-fold
Caution: Twisted-pair cable required
Computer 2
IP: 192.168.1.2
HUB
internet
!
Printer 1
IP: 192.168.1.2
. . .
. . . Printer 1
IP: 192.168.1.3
page.
Interfaces
Printer 2
IP: 192.168.1.4
