Figure 8. Top view
Table 27. Top view locations
Index number
5
6
7
8
9
10
11
12
13
76 Power Systems: Problem analysis, system parts, and locations for the 5104-22C, 9006-12P, 9006-22C, and
9006-22P
FRU description
Disk drive backplane
Fan 1
Fan 2
Fan 3
Fan 4
Fan 5
Fan 6
Fan 7
Fan 8
FRU removal and replacement
procedures
See Removing and replacing the
disk drive backplane in the
9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
See Removing and replacing fans
in the 9006-12P.
