If
No:
9. Update the BMC firmware by using a USB device. Complete the following steps:
a) Ensure that the USB device is formatted by using the VFAT file system.
b) Insert the USB device into the system if you have not already done so.
c) Type mount and press Enter.
Is the following output displayed?
/dev/mapper/sdb1 mounted on /var/petitboot/mnt/dev/sdb1
If
Yes:
No:
10. Complete the following steps:
a) Type cd /var/petitboot/mnt/dev/sdb1 and press Enter.
b) To update the BMC firmware, type the following command and press Enter:
./pUpdate -f bmc.bin -i bt, where bmc.bin is the name of the BMC image file.
c) Allow at least 2 minutes for the BMC to reboot. Does the problem persist?
If
Yes:
No:
11. Complete the following steps:
a) Type mkdir /tmp/media and press Enter.
b) Type mount /dev/mapper/sdb1 /tmp/media and press Enter.
c) Type cd /tmp/media and press Enter.
d) To update the BMC firmware, type the following command and press Enter:
./pUpdate -f bmc.bin -i bt, where bmc.bin is the name of the BMC image file.
e) Allow at least 2 minutes for the BMC to reboot. Does the problem persist?
If
Yes:
No:
12. Replace the system backplane.
• If your system is a 5104-22C or 9006-22C, go to "5104-22C or 9006-22C locations" on page 63
to identify the physical location and the removal and replacement procedure.
• If your system is a 9006-12P, go to "9006-12P locations" on page 75 to identify the physical
location and the removal and replacement procedure.
• If your system is a 9006-22P, go to "9006-22P locations" on page 91 to identify the physical
location and the removal and replacement procedure.
This ends the procedure.
4 Power Systems: Problem analysis, system parts, and locations for the 5104-22C, 9006-12P, 9006-22C, and
9006-22P
Then
This ends the procedure.
Then
Continue with the next step.
Go to step "11" on page 4.
Then
Go to step "12" on page 4.
This ends the procedure.
Then
Go to step "12" on page 4.
This ends the procedure.
