IBM Power System Series Problem Analysis, System Parts, And Locations page 45

Table 10. Sensor information, event description, and service action for the 5104-22C, 9006-12P,
9006-22C, or 9006-22P (continued)
Sensor name (Sensor ID)
• P1-DIMMA1 Func (0x10)
• P1-DIMMA2 Func (0x11)
• P1-DIMMB1 Func (0x12)
• P1-DIMMB2 Func (0x13)
• P1-DIMMC1 Func (0x14)
• P1-DIMMC2 Func (0x15)
• P1-DIMMD1 Func (0x16)
• P1-DIMMD2 Func (0x17)
• P2-DIMMA1 Func (0x18)
• P2-DIMMA2 Func (0x19)
• P2-DIMMB1 Func (0x1A)
• P2-DIMMB2 Func (0x1B)
• P2-DIMMC1 Func (0x1C)
• P2-DIMMC2 Func (0x1D)
• P2-DIMMD1 Func (0x1E)
• P2-DIMMD2 Func (0x1F)
Event description
Configuration Error
Beginning troubleshooting and problem analysis 31
Service action
Complete the following steps:
a. If the sensor name is P1-
DIMMA1 Func, ensure that
P1-DIMMA1 is seated
properly. If the sensor name
is P1-DIMMA2 Func, ensure
that P1-DIMMA2 is seated
properly. And so on.
b. If you recently installed or
replaced memory DIMMs,
ensure that the DIMMs are
plugged in the correct
memory slots.
c. If the sensor name is P1-
DIMMA1 Func, replace P1-
DIMMA1. If the sensor name
is P1-DIMMA2 Func, replace
P1-DIMMA2. And so on. Go to
"5104-22C or 9006-22C
locations" on page 63,
"9006-12P locations" on page
75, or "9006-22P locations"
on page 91 to identify the
physical location and removal
and replacement procedure.
