Table 19. Front view locations (continued)
Index number
7
8
9
10
11
12
Figure 2. Top view
64 Power Systems: Problem analysis, system parts, and locations for the 5104-22C, 9006-12P, 9006-22C, and
9006-22P
FRU description
HDD 6
HDD 7
HDD 8
HDD 9
HDD 10
HDD 11
FRU removal and replacement
procedures
See Removing and replacing a
disk drive in the 5104-22C or
9006-22C.
See Removing and replacing a
disk drive in the 5104-22C or
9006-22C.
See Removing and replacing a
disk drive in the 5104-22C or
9006-22C.
See Removing and replacing a
disk drive in the 5104-22C or
9006-22C.
See Removing and replacing a
disk drive in the 5104-22C or
9006-22C.
See Removing and replacing a
disk drive in the 5104-22C or
9006-22C.
