Table 35. Front view locations (continued)
Index number
9
10
11
12
*For more information about the placement of HDD and NVMe FRUs, see Drive installation information for
the 9006-22P system.
Figure 16. Top view
Table 36. Top view locations
Index number
13
14
92 Power Systems: Problem analysis, system parts, and locations for the 5104-22C, 9006-12P, 9006-22C, and
9006-22P
FRU description
HDD 8 or NVMe 0*
HDD 9 or NVMe 1*
HDD 10 or NVMe 2*
HDD 11 or NVMe 3*
FRU description
Disk drive backplane
Fan 2
FRU removal and replacement
procedures
See Removing and replacing a
disk drive in the 9006-22P.
See Removing and replacing a
disk drive in the 9006-22P.
See Removing and replacing a
disk drive in the 9006-22P.
See Removing and replacing a
disk drive in the 9006-22P.
FRU removal and replacement
procedures
See Removing and replacing a
disk drive backplane in the
9006-22P.
See Removing and replacing fans
in the 9006-22P.
